X-Racer F303 Flight Controller Released

FPVModel.com is happy to annouce that the X-Racer F303 flight controller is newly released. X-Racer was designed for the serious racer. We have followed the idea of simplicity and kept the basic rugged design of servo style pinouts so you dont have to worry about the fragility of plastic connectors in a crash.

This X-Racer flight controller only comes in one version...ACRO! This is not a flight controller that is designed to fit the needs of everyone, it is a flight controller designed to fit the needs of racers and free style flyers.

X-Racer backed by FPVMODEL's reputation giving you a flight controller you can trust.

FEATURES:

• Built in high capacity black box featuring 16mb flash memory. This will allow you to store an entire days worth of flights while you are out in the field burning through multiple batteries and flights. Next generation F3 processor for efficient flight calculations and those lower loop time youve been reading about.
• The size of the flight controller follows the form thats so typical in all the others allowing you to mount to the majority of the frames out on the market without the need of changing mounting holes on most base plates.
• 8 PWM I/0 lines for ESCs and added options you may choose.
• Supports Sbus, SumH, SumD, Xbus, PPM, PWM recievers but has a recommended and weight saving direct connection specifically for Sbus, which is our recommended connection for flight control.
• Buzzer port for audible lost model location.
• Convienent pin outs for easy, reliable soldering.
• Only available in Acro style, no barometer or magnetometer.

SOFTWARE:

The X-Racer flight controller runs on the open source Cleanflight software and its compatible with the Boris B. Betaflight firmware. The hex file to use is spracingf3 hex.

WARNINGS:

Failure to adhere to these warnings will void your warranty and destroy your flight controller.

• Observe polarity at all times. Double check all connections before applying power. It is very common for users to accidentally reverse polarity, try not to let it happen to you.
• After double checking all connections its a good idea to triple check connections...positive to positive, negative to negative.
• Make certain all channel inputs match corresponding outputs or else undesired flight characteristics will happen.
• Keep magnets away from flight controller.

TOP VIEW

BOTTOM VIEW

ZMR250 V2 Upgraded To Version V2.1

FPV Model has just upgraded its ZMR250 frame from V2 to V2.1. The new frames come with angled camera plates, and available in different colors, including black, silver, red, gold.

The reason of this change is to make ZMR250 V2 a more suitable multirotor for FPV during racing. However, the V2 is still available for sale as some pilotrs prefer straight camera plate.

ZMR250 V2: http://www.fpvmodel.com/zmr250-v2-250mm-carbon-fiber-mini-fpv-quadcopter-frame-kit-with-pcb-board-and-led_g1005.html

ZMR250 V2 Special Edition: http://www.fpvmodel.com/zmr250-v2-1-mini-quad-frame-kit-w-pdb-special-edition_g1084.html

FPVmodel.com Black Friday & Cyber Monday Super Sale

It's that time of year again!

Thanksgiving is here, and Christmas shortly thereafter... but in between? Black Friday and Cyber Monday!!!

FPVmodel is going to kick off the Black Friday & Cyber Monday with a sales event that can not be beat! Starting November 27th and going through November 30th, we are going to offer deals you will not find anywhere else.

We have lots of items lined up at fantastic bargains. The hottest selling ZMR250 V2 now 7% off. Hawkeye Little Pilot monitor original price $126USD, now sold at $98.28 USD only.  Skyzone RC702 monitor 30% off, now only $108.43 USD.

Furthermore, you can enjoy a further discount of 6% off Christmas promotion by using the coupon code santa6%.  It means that you will pay far more less than the price listed at fpvmodel.com.

For example, the Skyzone 3D goggles V3 original price $529 USD, now $507.84 plus free shipping. With further 6% off, actually you only need to 474.55 on such a state of art product.

All these special offers are only available from November 27th to November 30th. So what are you waiting for? Come and check these amazing deals at http://www.fpvmodel.com/black-friday_c127.html.

FPVmodel.Com Christmas & Winter Special Promotion

Seasons greetings! FPVmodel.Com is having a Year-end Sales event! Extra sitewide discount of 6% off, savings up to 50% off.

From November 11th, 2015, and going through January 3rd, 2016, we are going to offer deals that you can not find anywhere else. You can enjoy a discount of 6% off by using the coupon code SANTA6% at the checkout page.

For example, except the free shipping, you will save extra $18.00 USD on purchasing 6 FPVmodel Race Gates, save $32.34 USD on purchasing a set of Skyzone 3D goggles White Edition.


These deals cannot be beat and we are continuing to strive to show you we are the best at what we do. If you are building on budget, then please do not miss this opportunity.

Furthermore, you will have the chance to be the first one to own ZMR150 and colored ZMR180 & ZMR250 V2. We have taken the time to make sure these are the ZMR mini quads you are looking for. Our carbon fiber has been sourced and quality checked to ensure that you are getting the best quality 3k carbon fiber around. This CF is backed with FPVmodel's name so you can trust that it is top of the line.

FPV too expensive? Join FPVmodel Affiliate Program and Make Money!

>> What is FPVmodel Affiliate Program?

FPV hobby is too expensive? Why not join our affiliate program to make extra money?

You do not need a website, do not need a store, do not actually sell the products. Making extra money is so easy with our affiliate program. What you need to do is to put the links of our products on your website, blog, social media, related RC forums, or anywhere else, then we will send you the commission on the sale that you have successfully refered.

>> How Does FPVmodel Affiliate Program Work?

Simply post an affiliate URL on your website, blog, social media, RC forums, or anywhere else. If an end customer comes to visit FPVmodel.com via the link you posted and make an effective purchase (successfully paid), you will receive the commission on the purchase. Any purchase that made by the customer within 15 days of clicking your link will be counted into your commission.

Your commission can be withdrawed to your Paypal account or paid via Western Union. Or it can be used for purchasing goods at FPVmodel.com.

1. You post the FPVmodel affiliate ads or link. The link contains a unique affiliate tracking number that can track the sales amount that refered by you.

2. An end customer clicks the link. Once he or she registers, he/she will be affiliated to you.

3. The end customer makes a purchase within 15 days.

4. You Receive the commission of the sale.

>> How Much Commission Can I Receive?

Your commission will be calculated as a % of total effective orders that refered by your posted ads & links. The rate is based on your affiliate membership as shown in below table. Each membership has a different commission rate. The more the sale you made, the more the commission you will gain!

>> How Can I Join the Affiliate Program?

Everyone can join the affiliate program without prior contact with FPV Model. After login, you will find the affiliate program section on the left column of account details.

Click into the links, you will get the referal links with a unique number which is used for tracking the sales made thru the links you posted. The unique number is generated for you only.

When you want to recommend our products to your friends on RC forums, Facebook, blogs or somewhere else, do not forget to put the referal code after the links just like the ones shown as above. Then you will make money.

>> How Can I Receive My Commission?

You can withdraw the money via Paypal or Western Union transfer. Please note that the minimum withdrawal amount is $20 USD.

>> How Do I Generate Banner Referral Links?

If you would like to put our banners onto your own website or blog, please go to My Account -> Affiliate Program -> Referral Code -> Banner Referral Code. Select the banner you want and generate the code to add onto your website or blog. Once the customer clicks on the banner and make a purchase on FPVmodel.com within 15 days, you will earn the commission.

>> How Do I Get the Referral Links?

1. Add the referral links manually.

You can add the referral number to any of our URL links. For example, if your referral code is BFCB0FE6740CCD61, simply add ?u=BFCB0FE6740CCD61 after the URL. Your referral links will be like following:

Site Referral Url: http://www.fpvmodel.com/?u=BFCB0FE6740CCD61
Product Referral Url: http://www.fpvmodel.com/zmr250-v2-carbon-fiber-mini-fpv-quadcopter-frame-without-pdb_g1071.html?u=BFCB0FE6740CCD61
Category Referral Url: http://www.fpvmodel.com/mini-quad-hq_c136.html?u=BFCB0FE6740CCD61

2. Generate Referral Links Automatically

Please go to My Account -> Affiliate Program -> Referral Code -> Link Referral Code. Search the products that you want to recommend to others, and then clickGet Code.

>> Why My Earnings are Pending?

There are three status of the commissions you earned: Pending, Active and Cancelled.

Pending: It means the commissions can not be withdrawed or used temporarily. Please allow 30 days after order posted in case there is a cancellation or a refund with the order.
Active: It means that you can now use the money you have earned to buy the products at FPVmodel.com, or directly withdraw the money.
Cancelled: It means the orders may have been cancelled or refunded, the commission is ineffective.

FPVmodel Now Stocking Littlebee 20A ESC

A batch of FVT Littlebee 20A ESCs just arrived at FPV Models warehouse and now available for sale. http://www.fpvmodel.com/fvt-littlebee-20a-mini-esc-2-4s-_g1082.html

FVT Littlebee 20A ESC has been well received in the market and it is considered to be the most closest competitor to KISS ESC.

It is a super compact, lightweight, high performance speed controller for your racing multi-rotor. Pre-flashed with BLheli and ready to use with Oneshot (aka oneshot125 / PWMsync) mode via compatible flight controllers running Cleanflight or similar.

Specifications:

- Input: 2-4s Lipo
- Constant: 20 Amps
- Burst: 30 Amps
- Weight: 4g
- Dimensions: 23x12.5x3mm
- Motor wire: 70mm
- Signal wire: 120mm
- PCB - 4 Layer Blind Pole PCB - 3oz Pour
- Mosfet: All N channel
- BEC: None

Paul and Thomas from BMSWeb has ever made an informative review on the Little Bee ESCs:

20Amp Little Bee ESC vs SN20ABy BMSWeb

10X Zoom 1080P WDR Camera from FPVModel.com

FPV Model just unveiled a new 10x zoom 1080P WDR Camera with HDMI/AV output, OSD, DVR, Snapshot and playback functions. The product can be purchased at http://www.fpvmodel.com/10x-zoom-1080p-wdr-camera-with-hdmi-av-output-osd-dvr-snapshot-and-playback_g1058.html.

Larger aperture and better view. This is the newest 10x Zoom 1080P WDR (Wide Dynamic Range) Camera.  Coming with the original Panasonic lens, its nightshot view and picture quality will not fail your expectations. Comparing with other 10x zoom cameras, the most obvious improvement is the telephoto.

This is a new complete performance 10x zoom camera set. It features new HDMI and AV output, also includes the OSD menu option isplay, microphone, DVR and playback function.

With the new remote control cable, it can be used for taking pictures when flying and wont stop the video recording (picture pixel: 1920 x 1200), also for changing to manual focus as you wish when auto focus cant deal with the complex background.

The excellent camera is a perfect choice for FPV pilot,  detailed specifications are as follow:

SPECIFICATIONS:

New Wide Dynamic Range Function
Voltage input:DC 9-12V
CMOS:1/4 inch,wide dynamic,low noise
Interface:HDMI and AV output,(cant work at the same time and forbid disconnecting when working）
Power: 1.3w(static)-2.1w(dynamic)
Video format: NTSC and PAL selectable(default is NTSC)
Optical zoom: 10X, f=4.9 to 49mm
Video Pixel: 300W,1920(H)X1080(V)
Picture:pixel: 1920 x 1200
Video output: AV:1080p, 30FPS, CVBS,HDMI: 720P 60FPS
Minimum illumination: color 0.1Lux@F1.6
S/N: 48 DB
Auto gain, auto white balance
Elextronic shutter: Auto
Autofocus,speed: 1s
Menu display, supports DVR and video playback
Microphone: Yes
Size(L*W*H): 63x44x54(mm)
Working temperature: 0C- 55°
Weight: 180g

Comparing to Previous Version 10X Camera:

Winners Of 1st ZMR250 Video Competition Announced

FPV Model is pleased to announce that Mr. Roman Eelmaa has won the $1,000 cash prize and a ZMR V2 ARF Pro for the First ZMR250 Video Competition. The second place goes to Hector basil hind, his prize is a ZMR250 V2 ARF Pro. The third place goes to Krzysztof Chartanowicz, his prize is a ZMR V2 ARF. Other 8 winners will receive a ZMR250 V2 frame kit each.

Congratulations to all the winners! Please let us know your contact information, including name, address, zip code, telephone and E-mail, we will send the prizes to you. You can email us or PM us via facebook.

We would like to say Thank You to all that have participated!! It is much appreciated.

During the competition, we received 81 entries totally.  All the entries can be viewed at http://www.fpvmodel.com/video. The winners will not just only receive the prizes from FPV Model, but also have the chances to review some of our newest products in the future.

The complete winner list is as follow:

Number 1
Pilot: Roman Eelmaa
Prize: $1,000 Cash & ZMR250 V2 ARF Pro
https://www.youtube.com/watch?v=2gVsawly-iA

Number 2
Pilot: Hector Basil Hind
Prize: ZMR250 V2 ARF Pro
https://www.youtube.com/watch?v=AlLSzyHMu3c

Number 3
Pilot: Krzysztof Chartanowicz
Prize: ZMR250 V2 ARF
https://www.youtube.com/watch?v=3M45nP4J9BU

Number 4
Pilot: Thomas Bitmatta
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=4_B3oNFd844

Number 5
Pilot: Paul Park
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=3BuZ85S7IlY

Number 6
Pilot: Akaki Kuumeri
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=E8Y9alYVYao

Number 7
Pilot: Justin Hood
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=4KPKq8VJICM

Number 8
Pilot: Anuar Nakyssov
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=eVFcpbLVAsQ

Number 9:
Pilot: Julien Leteve
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=1FOMc-xqrpw

Number 10:
Pilot: Александр Сорокин
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=LVvGOTTSQ7c

Number 11:
Pilot: Stewart McSpedden
Prize: ZMR250 V2 Frame Kit
https://www.youtube.com/watch?v=vzEZZQ7DzuY

FPV Model Released Its New ZMR180 Mini Quad

The ZMR180 is a micro quad designed with "fun" in mind. Agile, quick, and small all fit together with this kit and its a blast to fly. Keeping simplicty in mind this frame has high quality 3mm bottom plate and a 1.5 mm top plate. Using the same carbon fiber that you find in FPVMODELs ZMR250 V2, you can rest assured that this is NOT the run of the mill cheap eBay Carbon Fiber that most others sell. This CF is backed with FPVMODELs name so you can trust that it is top of the line.

The ZMR180 is an awesome time to be had and you will find the smaller size can zoom through gaps that were previously not even considered with a 250 sized quad.

The ZMR weighs in at 72g including the given mounting hardware and spacers allowing for an ultra-light weight build yet leaving plenty of build room for adding all necessary FPV gear. If you wanna add more muscle, pick the ZMR180 with the larger mounts for 22xx motors.

Hurry up and get yours now, they are "flying" off the shelves.

Buy the ZMR180: http://www.fpvmodel.com/zmr180-180mm-carbon-fiber-mini-fpv-quadcopter-frame-kit-with-pcb-board_g1065.html

Feiyu FY-WG 3-Axis Wearable Gimbal for GoPro and Similar Action Camera

The Feiyu FY-WG 3-Axis Wearable Gimbal is a miniaturized version of Feiyus handheld gimbals, offering motorized 3-axis stabilization in a compact, wearable form factor for GoPro HERO4, HERO3+, HERO3, and similarly sized action cameras. Designed with flexibility in mind, the FY-WG features 1/4"-20 threaded holes for horizontal, vertical, or inverted mounting onto a variety of support devices. It is can also be used with any accessory the uses the standard GoPro three-prong mount thanks to an included adapter, letting you capture all of the immersive action camera shots that youre accustomed to, but with full motorized 3-axis stabilization. For streamline operation, a single button turns the gimbal on and lets you switch between operating modes. You can also plug-in an optional remote control for adjusting pan, tilt, and roll angles and other calibration settings.

Camera Compatibility

Compatible with GoPro HERO4, HERO3+, HERO3, AEE action cameras, and other models with similar dimensions. There is also enough room to accommodate an attached GoPro LCD BacPac.

Flexible Mounting Options

Two 1/4"-20 threaded holes lets you mount the camera horizontally, vertically, or inverted. It can also be used with any accessory that has a standard GoPro three-prong mount using an included adapter.

Operating Modes

Pan Following Mode: Locks tilt and roll axes. Camera smoothly pans to follow the direction of the handle.
Tilt and Pan Following Mode: Locks roll axis. Camera smoothly follows the pan and tilt motion of the handle. All Axis Lock: Locks the pan, tilt, and roll axes of the camera in the position it is in when mode is activated.
Inverted Mode: Allows you to turn the gimbal upside-down. This mode is an inverted version of the Pan Following Mode.
Standby Mode: The gimbal remains on but the motor is shut down.

Camera Orientation Detection System

No matter how your camera is mounted (left-aligned or right-aligned, upright or inverted), the FY-WG will identify the mounting position and automatically make the appropriate adjustments to its configuration.

Single-Button Operation

A single button is used to turn the gimbal on/off and switch between operating modes.

Compatible with Optional Remote Control

An optional remote control is available that enables pan, tilt, and roll angle adjustment, as well as other calibration settings. For manual tilt adjustment, simply hold the camera in the desired position for about half a second to register the setting.

Additional Features

• Weighs only 6.6 ounces
• Consumes less than 10 microamps of power on standby
• Powered using two 900mAh 16340 type batteries (four batteries included)

 *Camera not included.

ZMR250 V2 w/ New PDB Released

FPV Model is glad to annouce that the PDB of ZMR250 V2 now has been upgraded from V1.0 to V1.2.

We have taken the advise of many and reworked the PDB. It now features ESC pads on the top and bottom of the board. Traces and main power distribution have been routed in a manner to avoid running under the arms. Optional 12V regulator w/ built in LC filter is now available.

Besides, the issue of misaligned MinimOSD solder pins that may exist in the previous version now solved. Also, the arms for fitting 2204/2206 motors are selectable.

Except the ZMR250 V2 frame kits, FPV Model now also offer series of ZMR250 V2 ARF packages at a discounted price, including two ARF Pro packages that come with T-motor brushless motors.

Frame Kit only: http://www.fpvmodel.com/zmr250-v2-250mm-carbon-fiber-mini-fpv-quadcopter-frame-kit-with-pcb-board-and-led_g1005.html

ARF Kits (Standard): http://www.fpvmodel.com/zmr250-v2-250mm-mini-quadcopter-fpv-arf-combo_g1006.html.

ARF Pro w/ T-motor MN2204/MN2206 Motors: http://www.fpvmodel.com/zmr250-v2-arf-pro-w-t-motor-mn2204-mn2206-motors-optional-_g1049.html

ARF Pro w/ T-motor MN1806 Motors: http://www.fpvmodel.com/zmr250-v2-arf-pro-w-t-motor-mn1806-motors_g1055.html

ZMR250 V2 Build Manual

Congratulations on the purchase of the ZMR250 V2 Mini FPV Quadcopter! This mini quadcopter is a ton of fun and building can be a really enjoyable experience too. We hope this manual will assist you with your build.

Recommended Parts for the Build:

ZMR250 V2 250MM mini quadcopter frame kit x 1
Dragonfly MC1806 2300KV Brushless Motor x 4 (2cw+2ccw)
DYS SN20A Mini ESC x 4
Dragonfly 5030 CW/CCW props x 2 pairs
Naze32 Acro Funfly flight controller x1
SONY Effio-e 4140+811 1/3 CCD 3.6mm Lens 700TVL camera x 1
AOMWAY 5.8g mini 200mw 32CH transmitter x 1
Velcro Battery Strap  x 2
FPV 1.2G 5.8G Micro BEC 12V x 1
5.8G clover 3-leaf TX antenna x 1
20CM servo extension cable x 2
3M double sided adhesive tape x1

If you are not sure about what spare parts are required, just simply refer to the ones that included in theZMR250 V2 ARF Package.

Now lets start the building.

1. Solder the Transmitter and Camera

Cut the wires of camera to suitable length and solder them to PDB.
Red wire: Power
Black Wire: GND
Yellow: Signal

Solder the power supply wire and video wire (yellow) of transmitter to PDB.


2. Install OSD

The OSD firmware must be flashed and compatible to the Flight Controller before installation. If you don’t need to install the OSD, please just skip this step.

Solder the pin headers onto PDB.

Install the OSD on PDB. Insert it onto the pin heads and soldered. After secured, cut off the unnecessary length of pins.

3. Install the Buzzer

Pay attention to the positive pole “+” on the buzzer.  It needs to be soldered to the buzzer location on PDB.

Cut off the unnecessary pins.



4. Install ESCs

Solder the ESCs onto PDB.


The black wires can be parallel connected to the negative pole “-”.


5. Install Brushless Motors


The motor’s rotation direction can be changed by changing any two wires.

6. Extension


If the OSD and buzzer are installed, then you’ll need to use the supplied wires to solder onto PDB. Please take notice of wire length.


7. Install Flight Controller

Notice on the flight controller: It doesn’t require for soldering if the ESCs have no BEC. The flight controller can be powered by soldering to “5V” (circled in red).



8. Install ZMR250 V2 Frame

Important Reminder: In order to protect the PDB from short circuit, please use the supplied insulation washers when fastening arms to the PDB.

Way to go! You’ve almost completed the ZMR250 V2 build. Power on, and you are now ready to fly!
